How to load a roll of label into the printer:

1. Gently pull apart the spool.
2. Carefully slide the roll of labels onto the spool, ensuring a snug fit. Push the roll firmly onto the spool, ensuring the notches on the spool's base enter the cardboard core of the labels. Make sure there is no gap between the spool's base and the label roll.
3. Pick up the remaining piece of the spool and slide it down the spindle, securing it tightly on the roll of labels. Make sure that the notches securely engage with the cardboard core of the labels.
4. Place the label-loaded spool into the designated slot in the printer cover, ensuring the labels extend from underneath the roll.
5. Align the left edge of the label with the left edge of the label feed slot and insert the label into the slot.
6. The printer will automatically feed the label, stopping at the beginning of the first label.
7. Carefully lower the top cover.

Troubleshooting feed issues:

1. If the printer doesn't feed labels, ensure the first label is fully inserted and press the form-feed button.
2. In case the first label on the roll is incomplete, press the form-feed button to eject the partial label.
3. Carefully lower the top cover of the printer, securing the label roll in place.

Roll Dimension: 36mm x 89mm

Labels/Roll: 1x Roll - 260 labels per roll

Premium Quality: Water Resistant, Scratch Resistant, Chemical Resistant

Paper Type: Direct Thermal Labels

Adhesive: Permanent

Printers that are compatible with this label:

Dymo Label Writer 450

Dymo Label Writer 4XL

Dymo Label Writer 400/Twin Turbo

Dymo Label Writer 400 Duo
